The propyl silicone oil has a water-repellent effect while self-permeating, allowing water to exist on the surface in the form of water droplets.
Imported materials from Japan Shin-Etsu and Germany Wacker are used.
The molds manufactured by high-precision equipment ensure that the dimensional accuracy of the product is stable at ± 0.05mm.
Automatic Image Inspection
The 100% inspection of the product by the equipment guarantees that a non-conforming product will not flow out.
Adaptation requirements of waterproof plug and sheath:
When matching, the outer diameter of the wire sheath + 0.5mm ≥ the inner diameter of the waterproof plug ≤ the outer diameter of the wire sheath + 0.2mm. Example: The range of the outer diameter of the line sheath that the inner diameter of the waterproof plug 1.0mm can be adapted is 1.2mm-1.5mm.
When matching, the inner diameter of the sheath + 1.0mm> the outer diameter of the waterproof plug ≥ the inner diameter of the sheath + 0.2mm. Example: When the inner diameter of the sheath is 5.0mm, the outer diameter interval of the waterproof plug should be selected: 5.2mm-5.9mm.
The height of the waterproof plug shall not be higher than the height of the inner hole of the sheath.
